Charging capacity

Up to 22KW(11KW*2)

Input/Output power

400VAC±20%-50/60Hz-16A*2-3phase

RCD

RCMU(Type A+ DC 6mA)/ Type B RCBB(Optional)

Standby power

<5W

Measuring accuracy

1%

Energy Meter

MID certified

OCPP

OCPP1.6 Json(OCPP2.0 optional)

Communication

WIFI/Ethernet/4G(Optional)

User interface

LED / LCD(3.5’’) / RFID(mifare iso& IEC 14443A)

Certificate/Compliance

CE/RCC/ROHS/REACH/IEC/EN 61851-1，IEC/EN61851-21-2, IEC/EN 62955, EN300328, EN 301489-1/-17,EN62479.

Charging Interface

Type 2 Gun(5M Cable) *2

Special Protection

Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection,
Over/Under temperature protection

LCD screen

55”IPS 1920*1080 16:9 HDV 2500cd/m²

Application platform

Android 4.3 and above

Ad update

USB flash disk,SD card, wired network remote release

Protection

IP55(outdoor)

Special Protection

Topple & fall down protection

Cooling

Natural cooling

Operating temperature

-20℃ to +55℃

Product Dimensions

1900*916*280(L*W*H)mm
